16
386.257.1187
|
MetraOnline.com
CONFIGURATION MENU (CONT.)
Steering Wheel Controls
Left Knob Display Right Knob Display Radio Manufacturer Keynotes
r.d 1 Eclipse (Type 1) 1
r.d 2 Kenwood 2
r.d 3 Clarion (Type 1) 1
r.d 4 Boss (type 1)/Dual/Sony 1 (Boss)
r.d 5 JVC
r.d 6 Pioneer/Jensen
r.d 7 Alpine 3
r.d 8 Boss (type 4)/Visteon 1 (Boss)
r.d 9 Valor
r.d 10 Clarion (Type 2) 1
r.d 11 Boss (Type 2)
r.d 12 Eclipse (Type 2) 1
r.d 13 LG
r.d 14 Parrot 4
r.d 15 XITE
r.d 16 Philips
r.d 17 Kicker
r.d 18 JBL
r.d 19 Insane Audio
r.d 20 Magnadyne
r.d 21 Boss (type 3)
r.d 22 Axxera
Radio Detection
• Press the OK button on the steering wheel to start the auto detection process.
1. If the steering wheel controls don’t work properly it is possible to change the radio type.
2. Get to the radio type sub menu. Rotate the right climate knob until the correct radio type is
displayed on the knob display. Press the MAX AC button to set the new radio type.
3. If the AXSWC interface flashes Red (7) times, and an Alpine radio is not installed, that means
there is an open connection not accounted for. Verify that the 3.5mm jack is connected to the
correct steering wheel jack/wire in the radio.
4. The AXSWCH-PAR (sold separately) is required. Also, the software in the radio must be rev.
2.1.4 or higher.
5. If a Clarion or Eclipse radio is installed and the steering wheel controls do not function, change
the radio to Clarion (type 2) or Eclipse (type 2) respectively. If the steering wheel controls
still do function, refer to the Changing Radio Type document available at axxessinterfaces.
com.
6. If a Kenwood radio is installed and the L.E.D. feedback flashes (5) times instead of (2),
manually change the radio type to Kenwood. To do this, refer to the Changing Radio Type
document available at axxessinterfaces.com.
