Je bekijkt pagina 6 van 16
386.257.1187
|
MetraOnline.com
6
CONNECTIONS
From the 5858 harness to the aftermarket radio, connect:
• Black wire to the ground wire.
• Yellow wire to the battery wire.
• Green wire to the left rear positive speaker output.
• Green/Black wire to the left rear negative speaker output.
• Purple wire to the right rear positive speaker output.
• Purple/Black wire to the right rear negative output.
• Disregard the Red & White RCA jacks labeled “RSE/SYNC
®
/SAT”.
• Disregard the Red & White RCA jacks labeled “FROM 3.5”.
• Disregard the DIN jack.
• Tape off and disregard the following (2) wires:
Blue, Red
From the 16-pin harness with stripped leads to the aftermarket radio, connect:
• Red wire to the accessory wire.
• Blue/White wire to the amp turn on wire.
• Orange/White to the illumination wire. (If applicable)
• Gray wire to the front right positive speaker output.
• Gray/Black wire to the front right negative speaker output.
• White wire to the front left positive speaker output.
• White/Black wire to the front left negative speaker output.
• Blue/Pink wire to the VSS/speed sense wire (If applicable).
• Green/Purple wire to the reverse wire (If applicable).
• Light Green wire to the parking brake wire (If applicable).
• Tape off and disregard the following (5) wires:
Brown, Green, Green/Black, Purple, Purple/Black
