REV. 2/19/24 INST99-5858CH
3
KIT PREPARATION
From the factory climate & radio
control panel:
1. Remove (2) panel clips. (Figure A)
2. Remove (2) Torx screws securing the
a/c vents, then unclip and remove the
vents. (Figure A)
To the 99-5858CH radio bezel:
3. Clip the a/c vents in, then secure using
(2) #4 x 1/2” Phillips screws provided.
(Figure B)
4. Attach (2) factory panel clips. New panel
clips have been provided if the factory
clips are missing or damaged. (Figure B)
Sub-dash modification
5. Cut the shaded area as shown to allow
room for the aftermarket radio.
(Figure C)
Continue to Kit Assembly
(Figure A)
(Figure B)
(Figure C)
Cut shaded areas
