KIT PREPARATION
From the factory radio/climate control panel:
1. Unclip and remove the hazard switch
and traction control buttons.
To the 99-5834CH radio trim panel:
1. Attach the hazard switch and traction
control buttons. (Figure C)
2. Attach the (7)
panel clips
provided.
(Figure D)
Continue to Kit Assembly
(Figure B) (Figure D)
(Figure A)
For 4.2-inch display screen models only,
and if SYNC
®
is desired to be retained:
1. Remove the (4) 9/32’ screws securing
the brackets from SYNC
®
module.
2. Attach the
SYNC
®
module brackets
to
the SYNC
®
module using the (4)
#8 x 1/2” Phillips pan-head screws
provided. (Figure A)
3. Secure the module into the lower
sub-dash using the factory hardware
removed in step 7 of dash disassembly.
(Figure B)
(Figure C)
