99-5825
1. Unsnap and remove the panel
over the display at the top of
the dash. (Figure A)
2. Remove two 7 mm hex screws
from the top of the radio panel.
(Figure B)
3. Unclip and remove the radio
trim panel including the vents.
(Figure C)
Dash Disassembly
(Figure D)
(Figure A)
(Figure E)
(Figure B)
(Figure F)
(Figure C)
2
4. Remove two 7 mm hex holding
radio and radio chassis together
(from top of panel). (Figure D)
5. Remove two T-20 Torx and unclip
the two vents from the factory
radio panel. (Figure E)
6. Remove two T-20 Torx from
passenger airbag light and remove
it. (Figure E)
7. A small cut is required in the sub
dash for clearance. (Figure F)
Continue to kit assembly
