Je bekijkt pagina 7 van 32
REV.
11/4/22
INST99-3018
7
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
INTERFACE COMPONENTS
• Axxess interface
• 3018 harness
• 16-pin harness with stripped leads
• 4-pin to 4-pin resistor pad harness
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Small flat blade screwdriver • Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Connections ...............................................................................................................................8-13
For models without an amplifier ....................................................................................... 8-9
For models with an analog amplifier ...............................................................................10-11
For models with a digital amplifier ..................................................................................12-13
Installation ...................................................................................................................................13
Programming ...............................................................................................................................14
Adjustments .................................................................................................................................14
Final assembly .............................................................................................................................15
Troubleshooting ...........................................................................................................................15
• Provides accessory power (12-volt 10-amp)
• Maintains the Retained Accessory Power (R.A.P.) feature
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains warning chimes
• Retains OnStar/OE Bluetooth
• Adjustable volume for chimes and OnStar
• Retains the factory AUX-IN jack
• Pre-wired ASWC-1 harness (ASWC-1 sold separately)
• Can be used in non-amplified, or analog/digital amplified models*
• Retains balance and fade†
• Micro “B” USB updatable
* Please reference the “Service Parts Identification” sticker located under the spare tire cover. If the RPO code UQA
is listed, then the vehicle is equipped with an analog “DELCO” amplifier. If the RPO code UQS is listed, then the
vehicle is equipped with a digital “BOSE” amplifier.
† Excluding digital amplified models
