1.800.221.0932
|
MetraOnline.com
14
PROGRAMMING ADJUSTMENTS
For the steps below, the L.E.D. located inside the interface can only be seen while active. The
interface does not need to be opened to see the L.E.D.
1. Ensure all entry points are closed including the hood, then start the vehicle.
2. Connect the 3018 harness to the wiring harness in the vehicle. The L.E.D. will initially be solid
Green to indicate the interface is powered.
3. After a few seconds the L.E.D. will turn solid Red while the interface automatically programs
to the vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
4. Once the interface has been programmed the L.E.D. will turn solid Green, then the radio will
come back on, indicating programming was successful.
5. Turn the key (or push to start button) to the off position, then open and close the driver’s
door.
6. Wait for the domelight and interface L.E.D. to go out. Then, unplug the A/C connector shown
in Figure A, of the Installation section, for 5 seconds.
7. Plug the connector back in, start the vehicle, then test all functions of the installation for
proper operation.
8. If the interface fails to function, refer to “Troubleshooting”, “Resetting the Axxess interface”.
Note: The L.E.D. will turn on solid Green for a moment, and then turn off under normal operation
after the key has been cycled.
Audio level adjustment (digital amplified models only):
• With the vehicle and radio turned on, turn the volume up 3/4 of the way.
• With a small flat-blade screwdriver, adjust the potentiometer clockwise to raise the audio
level; counterclockwise to lower the audio level.
• Once at a desired level, audio level adjustment is complete
Chime level adjustment:
• With the vehicle on, turn it off and leave the keys in ignition. Open the driver’s door;
chimes will be heard.
• Wait 10 seconds, and then with a small screwdriver, turn the potentiometer clockwise to
raise the chime level; counterclockwise to lower the chime level.
• When the chime is at a desired level, remove the keys from the ignition. This will lock the
chime volume at its current level.
OnStar level adjustment:
• Press the OnStar button to activate it.
• While OnStar is speaking, press the VOLUME-UP or VOLUME-DOWN button on the steering
wheel to raise or lower the OnStar level.
• If the vehicle doesn’t come equipped with steering wheel controls, locate the Black/Yellow
wire on the 3018 harness.
• While OnStar is speaking, tap the Black/Yellow wire to ground. Once the OnStar level is set,
it will stay at that level until the Black/Yellow wire is tapped to ground again.
