9
REV. 6/6/24 INST95-7640B
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
INTERFACE COMPONENTS
• 2008-2013 Non-NAV car side harness (LD-NIS2)
• 2010-2013 w/factory NAV car side harness (LD-NISNAV2)
• 2008-2009 w/factory NAV car side harness (LD-NISNAV1)
• 6 volt camera power step down (AXCSD-6V)
• 16-pin harness with stripped leads (LD-2NAVAMPL)
• Touchscreen
• Airbag assembly
• HVAC control panel
• External Speaker
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Small flat blade screwdriver
• Tape
• Wire cutter
• Zip-ties
TABLE OF CONTENTS
Connections.............................................................................................................................10-16
Non-NAV/Non-Amplified models 2008-2013 LD-NIS2 Harness ........................................10
Non-NAV/Amplified models 2008-2013 LD-NIS2 Harness ..................................................11
Amplified & Non-Amplified w/o NAV Camera Connection LD-NIS2 Harness................... 12
Amplified & Non-Amplified NAV models 2010-2013 LD-NISNAV2 Harness ...................... 13
NAV models 2010-2013 LD-NISNAV2 Harness......................................................................14
NAV models 2008-2009 LD-NISNAV1 Harness ..............................................................15-16
Installation ................................................................................................................................... 17
Programming............................................................................................................................... 18
Touchscreen Display Operation............................................................................................ 19-20
Steering Wheel Control Settings SWC.................................................................................. 21-22
Final Assembly........................................................................................................................... 22
LED Feedback Legend .................................................................................................................23
Troubleshooting.......................................................................................................................... 24
• Designed for amplified and non-amplified vehicles*
• HVAC displayed on 7" touchscreen
• Retains factory back up camera
• Retains factory AUX in
• Provides accessory power (12V 10-amp)
• Provides NAV outputs (parking brake, reverse, and speed sense)
• Retains audio controls on the steering wheel
• Retains safety chimes through an included off-board speaker
• Micro B USB updatable
Please Note: Supported Languages include English, Spanish and French
*Amplifier not retained in convertibles
