KIT ASSEMBLY
(CONT.)
Full size DDIN mounting in the
lower location (cont.)
6. Connect the airbag and hazard, then
snap the upper panel assembly over
the touchscreen and secure the bottom
two mounts using the factory hardware.
(Figure E)
7. Connect the new climate control and
snap the lower panel over the radio.
Secure at the bottom with the (2)
#8 x 3/8” truss head screws supplied.
(Figure F)
8. Snap the bottom trim panel assembly in
place. (Figure G)
(Figure E) (Figure F) (Figure G)
