REV. 6/6/24 INST95-7640B
3
DASH DISASSEMBLY
(CONT.)
2008-2013 vehicles:
3. Remove (2) screws at the bottom of the
radio/climate control panel and remove
panel. (Figure C)
4. Remove (2) screws at the bottom of the
factory display panel and remove panel
with the vents. (Figure D)
5. Remove the factory vents and save
them for Kit Assembly.
6. Remove (4) Phillips screws securing
the radio chassis and a/c amp bracket
assembly then remove the assembly
from the dash. (Figure E)
7. Remove (2) Torx screws securing the
a/c amp module to the radio chassis/
bracket assembly and save for Kit
Assembly. (Figure F)
Important Note: The A/C amp module must
be re-installed and connected for the vehicle
to operate correctly.
Continue to Kit Preparation
(Figure F) (Figure D)
(Figure E) (Figure C)
