15
REV. 6/6/24 INST95-7640B
HVAC CONTROLLER
14 Pin
6 Pin
HAZARD/AIRBAG
A/C
OFF
MODE
Front
Rear
Sub
AUX-IN
Rear View
SWC
White/Black -
NOT USED
Purple -
NOT USED
Purple/Black -
NOT USED
Green -
NOT USED
Green/Black -
NOT USED
Green/Purple -
Reverse
Light Green - Parking
Blue/White - NOT USED
Blue/Pink - VSS
Gray - NOT USED
Gray/Black - NOT USED
White -NOT USED
Red - Accessory
Orange - Illumination
Brown - NOT USED
LD-NISNAV1
24 Pin
16 Pin
2 Pin
2 Pin
24 Pin
2 Pin
14 Pin
6 Pin
FUSE
Black - Ground
Yellow - Battery Power
Green - Rear Left Speaker +
Green/Black - Rear Left Speaker -
Purple -
Rear Right Speaker +
Purple/Black -
Rear Right Speaker -
Gray - Front Right Speaker +
Gray/Black - Front Right Speaker -
White - Front Left Speaker +
White/Black - Front Left Speaker -
Blue/White - Amp Turn On
AFTERMARKET RADIO
HVAC TOUCHSCREEN (back)
TBD
Orange - TBD
Light Green - TBD
Blue/Pink - TBD
Green/Purple- TBD
16 Pin
LD-2NAVAMP
16 Pin
G37 ONLY
4 Pin
G37 ONLY
CARSIDE CONNECTORS
TO CHASSIS GROUND
32 Pin
Connect to Airbag/Hazard
harness located at upper
center panel location
*
RADIO CHASSIS
EXT SPKR
EXTERNAL SPEAKER
2 Pin
20 Pin
A
B
C
A
C
B
(Your radio’s features may vary)
NAV 2008-2009 MODELS (LD-NISNAV1)
