REV. 4/24/2025 INST95-6560B
3
KIT PREPARATION
(Figure D)(Figure B)
(Figure C)(Figure A)
From the factory control panel:
1. Pull the three knobs from the front of
the factory climate controls. They come
apart in three pieces. An outer ring, a
button and a rubber keypad or two.
(Figure A)
2. Remove (8) T-8 torx screws from the
back cover. (Figure B)
3. Unclip and flip up the larger circuit
board to expose and remove (6) Torx
T-8 screws. (Figure C)
4. Remove 10 T-8 Torx screws from the
outer edges of the circuit boards.
(Figure C)
5. Remove the circuit boards, rubber
keypads, and button assemblies.
Continued on the next page
