1.800.221.0932
|
MetraOnline.com
6
3.5mm jack - steering wheel control retention:
The 3.5mm jack is to be used to retain audio controls on the steering wheel control.
• Connect the 3.5mm jack into wired remote input from the aftermarket radio. Refer to the
manual provided with the radio if in doubt as to where the 3.5mm jack goes to.
CONNECTIONS (CONT.)
For models
with
a Shaker system:
• Connect the White RCA jack labeled “SUBWOOFER”, to the subwoofer out jack.
• Disregard the Red RCA jack labeled “CENTER CHANNEL”, it will not be used in this application.
• Enable Audio Output Attenuation in Configuration Settings after the kit has been
programmed.
For models
with
a Shaker Pro system:
• Connect the Red RCA jack labeled “CENTER CHANNEL”, to the subwoofer out jack.
• Disregard the White RCA jack labeled “SUBWOOFER”, it will not be used in this application.
• Enable Audio Output Attenuation in Configuration Settings after the kit has been
programmed.
4-pin harness with yellow RCA jacks:
This harness is to be used to add an aftermarket backup camera to the touchscreen display, if so
desired.
• Connect the Yellow RCA jack labeled “Rearview camera”, to the RCA jack on the aftermarket
backup camera.
• Disregard the Yellow RCA jack labeled “AUX video”, it will not be used in this application.
