ENGLISHen
12
7.2 If there is a risk of frost
Frost (< 4 °C) destroys the pump and
accessories as both always contain water!
Disassemble the pump and accessories and store
them in frost-free conditions (see chapter 8.2) if
there is a risk of frost.
Danger!
before any work on the pump:
- Unplug power cable;
- Ensure that the pump and connected accessories
are depressurised.
- Repair and maintenance work other than that
described in this section should only be carried
out by qualified specialists.
8.1 Regular maintenance
Check pump and accessories for damage, in
particular electrical and pressurised components,
and repair if necessary.
Check pressure lines for leaks.
Regularly clean the pump:
1. Rinse pump with clean water. Remove
persistent contamination with a brush.
2. To rinse the inside of the pump:dip pump into a
container of clean water and switch on briefly.
8.2 Disassembling and storing the pump
- Unplug power cable;
- Open the discharge line (open the water tap or
spray nozzle), allow water to drain off completely.
- Drain the pump completely. To do this:
- Unscrew the pressure line.
- Unscrew the suction hose if necessary (8).
- Store the device in a frost-free room (min. 5 °C).
- Keep out of the reach of children.
Danger!
before any work on the pump:
- Unplug power cable;
- Ensure that the pump and connected accessories
are depressurised.
Pump is not running
• No mains voltage.
- Check cables, plug, outlet and mains fuse.
• Mains voltage too low.
- Use an extension cable with an adequate
conductor diameter.
• Overload protection: automatic switch-off in case
of imminent overheating.
- After cooling down the pump starts by itself.
- Remedy the cause for overheating. Water too
warm? Long-term pumping with closed
pressure line? Is the suction area clogged, is
the pump blocked by foreign objects?
• Float switch does not switch pump ON when
water level rises.
- Make sure the float switch can move
unrestrictedly.
- Have the pump repaired if the pump does not
switch on despite sufficient mobility of the float
switch.
Motor hums, but does not start
• Pump blocked by foreign objects.
- Clean the pump. See chapter 8.
Pump does not deliver correctly
• Discharge hose kinked.
- Straighten discharge hose.
• Suction area clogged.
- Clean, see chapter 8.
• Discharge hose leaky.
- Seal discharge hose; tighten screw fittings.
• Delivery head too high.
- Observe max delivery head (see 'Technical
Specifications').
• Check valve jammed.
- The installed check valve prevents the water
from flowing back through the pump. The
check valve must be able to move freely for the
pump to deliver. See page 2, fig. B:
1. Unscrew the pressure line.
2. Pull the jammed check valve (1) up slightly
by its pin until it can move freely again.
3. Screw the pressure line back on.
The pump runs very noisily
• Pump is sucking air.
- Ensure that there is an adequate supply of
water.
- Foreign objects are present (clean pump)
TDP 6200/4 Inox: Pump runs continuously
• Float switch does not reach cut-out position.
- Make sure the float switch can move
unrestrictedly.
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
A Floating removal (water removal in the cleanest
area, directly under the surface of the water. For
connection to 1” spiral suction hoses). Order
no. 0903061359
B Suction hose set brass, 4 m, 1". Order no.
628797000
See www.metabo.com or the catalogue for a
complete range of accessories.
Danger! Repairs to this pump must only be
carried out by qualified electricians!
If the mains connection cable of this pump is
damaged, it must be replaced by the manufacturer
or an authorized service centre to avoid hazard.
Contact your local Metabo representative if you
have Metabo pumps requiring repairs. For
addresses see www.metabo.com.
For shipping: Empty the pump completely.
8. Maintenance, storage
9. Troubleshooting
10. Accessories
11. Repairs
