ENGLISHen
10
- Use Allen key (15)
2. Remove die and insert new die
3. Tighten hollow nut with 3 Nm
8.3 Replace the die holder
When assembling, it is best to hold the machine
horizontally.
1st Loosen knurl by at least 3 turns.
2. Pull out the die holder (10)
3. Insert a new die holder into the housing
4. Tighten the knurl (8)
Regularly empty the chip collection bag (16): Push
the bag off the hollow nut, open and empty chips in
suitable container To attach, place the chip
collection bag on the hollow nut and press until it
snaps into place (see P.2)
Use only original Metabo or CAS (Cordless Alliance
System) battery packs and accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating instruc-
tions.
Battery packs with different capacities:
Best.-Nr.: .................. 625596000 2,0 Ah (LiHD)
Best.-Nr.: .................. 625367000 4,0 Ah (LiHD)
etc.
Chargers:
Best.-Nr.: 627044000 ASC 55
Best.-Nr.: 627378000 ASC 145
etc.
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline
2012/19/EU on used electronic and electric
equipment and its implementation in national
legal systems, used power tools must be collected
separately and handed in for environmentally
compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U = Voltage of battery pack
B
St
= Maximum sheet thickness (sheet steel)
B
Al
= Maximum sheet thickness (aluminium)
h
0
= Stroke rate at idle speed
h
1
= Stroke rate at rated load
r
min
= Smallest curve radius
m = Weight without mains cable
Measured values determined in conformity with
EN 62841.
Permitted ambient temperature during operation:
-20 °C (-4°F) to 50 °C (120°F) (limited performance
with temperatures below 0 °C (32°F)). Permitted
ambient temperature for storage: 0 °C (32°F) to
30 °C (86°F).
Direct current (cordless machines)
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. Depending on the operating
conditions, the condition of the power tool or the
accessories, the actual load may be higher or lower.
For assessment purposes, please allow for breaks
and periods when the load is lower. Based on the
adjusted estimates, arrange protective measures
for the user e.g. organisational measures.
Vibration total value
(vector sum of three directions)
determined in accordance with EN 62841:
a
h
= Typical estimated acceleration
in the hand/arm area
(cutting sheet metal)
K
h
= Uncertainty (vibration)
Typical A-effective perceived sound levels
:
L
pA
= Sound pressure level
L
WA
= Acoustic power level
K
pA
, K
WA
= Uncertainty
During operation the noise level can exceed
80 dB(A).
Wear ear protectors!
9. Cleaning
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical Specifications
