18
Subject to errors and changes
12. DISPOSAL
For environmental reasons, do not dispose of the device in the
household waste. Please dispose of the device in ac
-
cordance with EC Directive – WEEE (Waste Electrical
and Electronic Equipment). If you have any questions,
please contact the local authorities responsible for
waste disposal.
13. TECHNICAL SPECIFICATIONS
Type IH 16
Model Air Mini
Dimensions
(W x H x D) 138.6 x 116 x 88.4 mm
Weight 0.85 kg ± 0,2 kg
Operating pressure Approx. 0.35–0.8 bar
Atomiser filling
volume
Max. 6 ml
Min. 2 ml
Medication flow rate Approx. 0.3 ml/min
Sound pressure Approx. 52 dBA
Mains connection 230 V~; 50 Hz; 230 VA
UK: 240 V~; 50 Hz; 240 VA
Operating conditions Temperature: +10°C to +40°C
Relative humidity: 10% to 95%
Ambient pressure: 700 hPa to 1060 hPa
Storage and
transportation
conditions
Temperature: −25°C to +70°C
Relative humidity: 10% to 95%
Expected service life
of device
Information on the service life of the
product can be found on the website
Aerosol values
according to
EN ISO 27427:2023
based on adult
breathing patterns
with sodium
salbutamol:
1) Aerosol delivery: 0.67 ml
2) Aerosol delivery rate: 0.06 ml/min
3) Fill volume dispensed in percent per
min. 1.38%
4) Residual volume: 0.8 ml
5) Particle size (MMAD): 2.07μm
6) GSD (geometrical standard deviation):
2.1
7) RF (respirable fraction < 5μm): 72%
8) Large particle range (>5μm): 28%
9) Medium particle range (2 to 5μm): 22%
10) Small particle range (<2μm): 50%
The serial number is located on the device.
Subject to technical changes.
Particle size diagram
Measurements were performed using a salbutamol solution with
a “Next Generation Impactor” (NGI).
The diagram may therefore not be applicable to suspensions or
highly viscous medications. You can obtain more detailed infor
-
mation from the manufacturer of your medication.
14. GUARANTEE / SERVICE
Further information on the guarantee and guarantee conditions
can be found in the guarantee leaflet supplied.
Notification of incidents
For users/patients in the European Union and identical regulation
systems (EU Medical Device Regulation (MDR) 2017/745), the
following applies: If a major incident occurs during or through
use of the product, notify the manufacturer and/or their repre
-
sentative of this as well as the respective national authority of the
member state in which you are located.
