Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
55
55
The tables show the setting options for constant light control (referred to as "CL" in the following):
ETS-Text
Dynamic range
[Default value]
Comment
Settings: Switching behaviour/control behaviour
Switch constant light
via…
• external object
• Presence (light channel 1)
Defining how the constant light
control is to be switched on
Time from switching on
to start of control
1 s – 5 min
[5 s]
Determination of the delay between
activation and start of regulation
Controller switches the
light Off
• not active
• active
Setting whether the controller may
switch off the light completely
Minimum dimming value
at dimming output
0 – 50 %
[0 %]
Setting the minimum dimming value
for the constant light control
Maximum dimming value
at dimming output
50 – 100 %
[100 %]
Setting the minimum dimming value
for the constant light control
Switch-on value “Day”
• parameter (settable
dimming value)
• Teach-in (learned value)
• calculate switch-on value
(over Lux value)
Determination of the value with
which the constant light control is to
be switched on
Dimming value at
switch-on “Day”
0 – 100 %
[80 %]
Only with setting "Parameter
(settable dimming value").
Sets the switch-on value for Day
Preset setpoint at
“Day”
100 – 750 Lux
[450 Lux]
Setpoint for Day mode.
Only with setting “calculate switch-
on value (over Lux value)”
Constant light control at
“Night”
• not active
• active
Activation of the constant light
control during Night Operation
Switch-on value “Night”
• parameter (settable
dimming value)
• Teach-in (learned value)
• calculate switch-on value
(over Lux value)
Determination of the value with
which the constant light control is to
be switched on
Dimming value at
switch-on “Night”
0 – 100 %
[20 %]
Visible if constant light control is
not active or, if active, with the
setting "Parameter (settable
dimming value)".
Sets the switch-on value for Night
Preset setpoint at
“Night”
25 – 500 Lux
[50 Lux]
Setpoint for Day mode.
Only with setting “calculate switch-
on value (over Lux value)”
Brightness value at
switch-on
• use last dimming setpoint
• use parameter value
Setting whether the last setpoint
from relative dimming or the scenes
should be used or the setpoint
should be loaded from the
parameters.
CL status sends value 1
• on readiness
• when control active
• when lock active
Setting for which action the status of
the CL is sent
