Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
39
39
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Active sensors
• ----
• 1---
.
.
• 1234
Setting which sensors are active for this
channel.
With 3 sensors, the selection is
correspondingly "---" to “123".
With 2 sensors “—” to “12”.
Trigger sensitivity at Day
1 – 8
[6]
Setting the triggering sensitivity in Day
mode
Trigger sensitivity at Night
1 – 8
[3]
Setting the triggering sensitivity in Night
mode
Presence sensitivity
1 – 10
[8]
Setting the sensitivity when presence is
detected
Reduce sensitivity for
sensors
not active
1--
-2-
to
-23
Setting to reduce the sensitivity of
individual sensors.
With 4 sensors, the selection is
correspondingly „1---" to „-234“.
With 2 sensors “1-” to “-2”.
Interference/motion filter
• not active, no
filtering
• active, filter
interferences/short
motions
Activation of a motion filter on standby
(= output is switched off)
Length of monitoring
time slot
1 – 5 s
[2 s]
Only if "Interference/ motion filter" is
set to "active, filter interferences/ short
motions".
Setting the number and length of
monitoring time slots for detecting the
channel
Number of monitoring
time slot
2 – 5
[3]
Follow-up time Day/Night
1 s – 4 h
[3 min]
Setting the follow-up time for Day or
Night operation
Locking or enabling object
• Lock object
• Enabling object
Setting whether a locking or enabling
object is to be used
Fallback of forced
guidance/lock
(General settings)
• not active
• active
Only available with lock object.
Setting whether or not the channel
should react to "Fallback forced
guidance/lock" in the menu “General
settings”.
For SCN-P360E3.03 only possible from
hardware revision R4.2!
Output objects for
Day/Night
• one common object
• separate objects
Setting whether to send via one object or
separate objects for Day and Night
Output object sends at
• Only ON
• ON and OFF
Output filter for the first output object
Output object sends cyclic
• not active
• 10 s – 60 min
Activation of cyclic sending for the first
output object
Table 17: Settings – Alarm/Message channel
