Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
19
19
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Active sensors
• ----
• 1---
.
.
• 1234
Setting which sensors are active for this
channel.
With 3 sensors, the selection is
correspondingly "---" to “123".
With 2 sensors “--" to “12”.
Sensitivity
• basic setting
(General setting)
• individual
basic setting: The values for sensitivity
from the "General settings" menu are
used.
individual: Individual values can be set
for the individual light channel. The
settings shown are the same as in the
menu "General settings".
Brightness
• basic setting or object
„Dark switch“ active
• Independent of
brightness
Basic setting or object „Dark switch“
active: The light channel uses the
brightness settings of the “General
settings”, but can be switched brightness-
independently with a "1" on the "Switch
dark" object.
Independent of brightness: The light
channel switches independently of the
measured brightness.
Channel mode
• fully automatic
• half automatic (manual
switching)
Setting whether the device operates as a
fully automatic or semi-automatic device
Motion filter in standby
• not active, no filtering
• active, filter short
motions
Activation of a motion filter in readiness
(= output is switched off).
Only in fully automatic operating mode!
Reduction of follow-up
time
• not active
• active
Setting whether a shortening of the
follow-up time is to be activated
Maximum duration for
short time presence
10 s, 20 s, 30 s,
Setting the maximum duration for a
short-time presence
Follow-up time for
short time presence
10 s, 20 s, 30 s, 45 s, 60 s, 90 s,
120 s
Setting the follow-up time for the short-
time presence
Follow-up time Day
1 s – 4 h
[3 min]
Setting the follow-up time for Day mode
Follow-up time Night
1 s – 4 h
[30 s]
Setting the follow-up time for Night mode
Table 4: Basic settings – Light channel
