Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
4
4
2 Overview
2.1 Overview Devices
The description refers to the following LED Indicators (order shown in bold):
• SCN-LED55.01 LED-Indicator, 55mm
o 12 RGBW LEDs, Logic and Converter functions
• SCN-GLED1W.01 Glass LED-Indicator, white
o 12 RGBW LEDs, Logic and Converter functions
• SCN-GLED1S.01 Glass LED-Indicator, black
o 12 RGBW LEDs, Logic and Converter functions
2.2 Usage & Areas of application LED Indicator
The LED Indicator serves as a reminder of certain states. In this case, each of the 12 LEDs can be
either normally switched on or flash in four different colors (red, green, blue, white) to show any
state. The 6 row elements can be individually labeled in both designs, the glass LED Indicator as well
as the 55mm LED Indicator.
In addition, the display features 8 logic blocks as well as an alarm and converter function. Via the
logic function, states or functions can be evaluated in detail by using AND/OR functions. In response
to its states, byte values or scene numbers can be sent.
Through the built-in alarm function interrupts can be triggered with the signal change of any LED. To
this end, 4 different alarm objects are available.
By using the converter function, temperature values, byte values and 2-bit values can be converted
to simple bit values.
