Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
17
17
Figure 8: Settings LED priority 1/2
The activation of the LED priority can be done via external objects, internal logic objects or internal
converter objects. The settings are the same as described in 4.2.1 LED Control.
Standardly, the priority is activated with the value 1. Via the parameter “invert object”, the priority
can be set as active at the value 0.
The display behavior of the LED at activation of the LED priority is the same like described in 4.2.2
LED Display behavior, but can be set individually for the LED priority.
If the parameter “Assignment of communication objects” is set to external object, an additional
object is shown, which can be connected individually:
Number
Name
Length
Usage
1
LED Priority 1
1 Bit
Controlling the LED Priority 1
2
LED Priority 2
1 Bit
Controlling the LED Priority 2
Table 8: Communication objects LED priority
