When a new absolute comfort setpoint is read in, a new basic comfort value is assigned to the
controller. There is a significant difference in the Smart room temperature controller between the
settings "dependent on comfort setpoint (basic)" and "independent setpoints".
Setting "depending on setpoint Comfort (Basic)".
This new basic comfort value (object “62”) also automatically causes an adjustment of the
dependent setpoints in the other operating modes, as these are relative to the basic comfort
value. All settings for setpoint shifting do not apply here, as a completely new base value is
assigned to the controller.
The specification of a setpoint via the communication object "61 - Setpoint setting" offers a
special feature. Here the new value is written to the basic comfort setpoint, a valid setpoint shift
is deleted and the controller automatically jumps to comfort, regardless of which mode the
controller was in before. This procedure is required for visualizations that make changes via
absolute setpoints. This ensures that the new setpoint sent is also reported back.
Setting "Independent setpoints".
Here, an individual absolute value can be specified for each operating mode. If, for example, the
setpoint is changed in Comfort mode (object "62"), the other setpoints remain unaffected.
A special feature is the common object "61 - setpoint setting". This always changes the setpoint
in the currently valid mode. If, for example, the controller is currently in Standby mode and the
value "20°C" is sent via object "61", the Standby setpoint is changed to "20°C" at this moment.
The following table shows the communication objects relevant for the setpoint change:
Number
Name/Object function
Length
Usage
61
Preset setpoint
2 Byte
General object for setpoint setting
62
Preset Comfort setpoint
2 Byte
Setpoint setting in Comfort mode
62
Preset (Basic) Comfort setpoint
2 Byte
Setpoint setting in Comfort mode
62
Combination object: Preset
setpoint
8 Byte
Setpoint setting via combined object.
Visible when "Heating" or "Cooling"
62
Combination object (Heating):
Preset setpoint
8 Byte
Setpoint setting via combined object.
Visible when "Heating and Cooling"
63
Preset Standby setpoint
2 Byte
Setpoint setting in Standby Mode
64
Preset Night setpoint
2 Byte
Setpoint setting in Night Mode
65
Preset Frost protection setpoint
2 Byte
Setpoint setting in Frost protection mode.
65
Preset Heat protection setpoint
2 Byte
Setpoint setting in Heat protection mode
66
Combination object (Cooling):
Preset setpoint
8 Byte
Setpoint setting via combined object.
Visible when “Heating and Cooling “
67
Send current setpoint
2 Byte
Outputs the currently valid setpoint
68
Manual setpoint shift (2Byte)
2 Byte
Shift of the setpoint relative to the preset
comfort setpoint.
Object is permanently displayed
69
Manual setpoint shift (1=+ / 0=-)
1 Bit
Increase/decrease the setpoint relative to
the preset comfort setpoints by the set step
width
69
Manual setpoint shift (1Byte)
1 Byte
Increase/decrease the setpoint relative to
the preset comfort setpoints by the set step
width
70
Send status setpoint shift
2 Byte
Sending the current status of the setpoint
shift
Table 49: Communication objects – Setpoint changes
