Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
42
42
4.4 Temperature controller
The temperature controller is activated via the "Operation mode" parameter.
Figure 22: Settings – Activation of the controller
The table shows the possible settings for the operation mode:
ETS-Text
Dynamic range
[Default value]
Comment
Operation mode
▪ not active
▪ Heating
▪ Cooling
▪ Heating and Cooling
Setting the controller operating mode.
The other settings depend on the set
control mode.
Table 29: Settings – Operation mode
If the setting "not active" is set for operating mode, the controller is deactivated and there are no
further configuration options for the controller. As soon as the controller has been assigned a
specific function, “Heating”, “Cooling” or “Heating & Cooling”, depending on the application,
further settings can be made, and the "Controller parameters" menu also appears on the left-hand
side.
The task of the control system is to adjust the actual temperature as close as possible to the
specified setpoint. To realize this, several setting options are available to the user. The controller
can influence the control value via 3 different control modes (PI control, 2-point control, PWM
control). In addition, an additional stage can be assigned to the controller.
In addition, the controller has 4 different operating modes (Frost/Heat protection, Night, Comfort,
Standby) for differentiated control of various requirement ranges.
Further functions of the controller are the manual setpoint adjustment, the dynamic setpoint
adjustment considering the measured outdoor temperature, the setpoint specification via
independent setpoints (as absolute values) as well as the operating mode selection after reset and
integration of blocking objects.
