Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
31
31
The associated communication objects are shown in the table:
Number
Name/Object function
Length
Usage
53
Air quality controller – Output level 1
1 Bit
Switching the 1st output level
54
Air quality controller – Output level 2
1 Bit
Switching the 2nd output level
55
Air quality controller – Output level 3
1 Bit
Switching the 3rd output level
56
Air quality controller – Output level 4
1 Bit
Switching the 4th output level
57
Day / Night –
Day = 1 / Night = 0, Night = 1 / Day = 0
1 Bit
Switchover between Day and Night
Operation
Table 19: Communication objects – Step controller Bit coded
For more information on the parameters that are not described in detail, see the following chapters:
4.3.2.1 General parametersFor more information on the parameters that are not described in detail,
see the following chapters:
4.3.2.1 General parametersFehler! Ungültiger Eigenverweis auf Textmarke.
4.3.2.7 Send setpoint/output cyclically
4.3.2.6 Behaviour at lock
4.3.2.7 Send setpoint/output cyclically
4.3.2.3 Specific settings – Step controller binary coded
The functionality of the binary-coded step controller is identical to that of the step controller (Bit-
coded) as described in chapter 4.3.2.2 Specific settings – Step controller Bit coded .
The only difference is that the output level is transmitted in binary code. Object 53 is bit 0, object
54 is bit 1 and object 55 is bit 2.
The following table shows the binary-coded switching of the output stage:
Normal step controller
Binary value
step controller binary coded
Level 0
000
Objects 53, 54 ,55 = 0
Level 1
001
Object 53 = 1, Objects 54 & 55 = 0
Level 2
010
Object 54 = 1 , Objects 53 & 55 = 0
Level 3
011
Objects 53 & 54 = 1, Object 55 = 0
Level 4
100
Object 55 = 1 , Objects 53 & 54 = 0
Table 20: Settings – Step controller binary coded
The following table shows the associated communication objects:
Number
Name/Object function
Length
Usage
53
Air quality controller – Output Bit 0
1 Bit
Setting the bit 0
54
Air quality controller – Output Bit 1
1 Bit
Setting the bit 1
55
Air quality controller – Output Bit 2
1 Bit
Setting the bit 2
Table 21: Communication objects – Step controller binary coded
