Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
27
27
The table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Controller actual value
▪ CO2
▪ VOC (ppm)
▪ VOC (IAQ Index)
▪ CO2 + Humidity
▪ VOC (ppm) + Humidity
▪ VOC (IAQ Index) + Humidity
Setting, which sensors the controller
uses as a basis for control.
Number of external
Room sensors
not active
1 … 10
Activation of additional, external
sensors.
When selecting one sensor in
"Controller actual value".
not active
1 + 1, 2 + 2 … 5 +5
Activation of additional, external
sensors.
When selecting two sensors in
"Controller actual value".
Air quality control with
humidity increase by…
not active
1 level … 4 levels
Setting whether increased humidity
influences the control.
Displayed if "+ Humidity" is active
for "Controller actual value".
Selection (levels/%) depending on
the controller type (PI or step
controller).
not active
25%, 50%, 75%, 100%
Threshold for
exceeding the air
humidity
0 – 100%
[75%]
Setting from which increase in
humidity the control reacts to it.
Follow-up time after
falling below
1 – 60 min
[30 min]
Setting of the time from when the
controller switches back to the
previous control after the value falls
below the threshold.
Figure 13: Settings – Air quality controller: General parameters
Controller actual value
Here you set which variable(s) the controller uses as a basis for control. This can be only one sensor
(CO2 or VOC) or two sensors (CO2 respectively VOC + humidity).
Number of external Room sensors
The parameter makes it possible to integrate further sensors into the control in addition to the
respective integrated sensor. This can be important if, for example, a central ventilation control
contains several rooms. Each room has its own sensor and all sensors are included in the
calculation.
If only one sensor is selected for the "Controller actual value", up to 10 external room sensors can
be set. If two sensors are selected (CO2 + humidity, VOC + humidity), 5 external sensors of both
types can be activated. The highest measured value is decisive for the level to be switched or the
control value to be sent.
Example:
Controller actual value: "CO2 + humidity", External room sensors: "5 + 5".
5 external CO2 sensors and 5 external humidity sensors can be included.
Special feature: If 5 CO2 sensors but only 3 humidity sensors are used with this setting, the unused
sensors are preset with the value "0" and do not influence the control.
