RTSM combined status (DPT 22.107)
This is a combined status according to DPT 22.107. The assignment is as follows:
Bit
Beschreibung / Description
Codierung / Encoding
0
Effektiver Wert des Fensterstatus
Effective value of the window status
0 = alle Fenster geschlossen/
all windows closed
1 = mindestens ein Fenster geöffnet/
at least one window opened
1
Effektiver Wert des Präsenzstatus
Effective value of the presence status
0 = keine Meldung einer Präsenz/
no occupancy from presence detectors
1 = mindestens ein Melder belegt/
occupancy at least from one presence
detector
3
Status der Komfortverlängerung
Status of comfort prolongation User
0 = Komfortverlängerung nicht aktiv/
comfort prolongation User not active
1 = Komfortverlängerung aktiv/
comfort prolongation User not active
Table 46: Assignment – RTSM combined status DPT 22.107
4.4.4 Operating mode after reset
The following table shows all available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Operating mode
after reset
▪ Comfort with configured setpoint
▪ Standby with configured setpoint
▪ Hold previous state and setpoint
Setting which operating mode
or behaviour is to be activated
after a bus voltage return.
Operating mode
after reprogramming
▪ Comfort
▪ Standby
Setting the operating mode
after reprogramming.
Only with the setting "Hold
previous state and setpoint".
Table 47: Settings – Operating mode after reset
• Comfort with configured setpoint
After a bus voltage return, the comfort is activated with the setpoint that was specified by
the ETS.
• Standby with configured setpoint
After a bus voltage return, the Standby mode is activated with the setpoint that was
specified by the ETS (Comfort setpoint minus Standby reduction).
• Hold previous state and setpoint
The temperature controller recalls the setpoint and mode that was set before the bus was
switched off. With this selection, the parameter "Operating mode after reprogramming"
can be used to additionally set which operating mode is active after reprogramming.
