Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
24
24
The table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Air quality traffic light
• Step output
• Scene output
• RGB output
• HSV output
Setting for what the output is to be
used as.
Sensor for Air quality
traffic light
• CO2
• VOC(ppm)
• VOC (IAQ Index)
Setting of the sensor according to
which the air quality light operates.
Hysteresis in
• percent
• ppm
When selecting „CO2“ and „VOC
(ppm)“
Setting with which unit the hysteresis is
determined.
When selecting „VOC (IAQ Index).
• percent
• IAQ
Hysteresis
0 … 20 %
[5 %]
Setting the hysteresis in „percent“.
10 … 500 ppm
[100 ppm]
Setting the hysteresis in „ppm“.
0 … 50
[5]
Setting the hysteresis for selection
„IAQ“
Traffic light with
• 3 levels
• 4 levels
Setting whether the traffic light should
work in 3 or 4 levels.
Colour for
level 1
level 2
level 3
level 4
Setting the colours for the different
levels.
- Only with "RGB or HSV output“.
- level 4 only with setting „4 levels“.
Scene number for
level 1
level 2
level 3
level 4
1 – 64
[1]
[2]
[3]
[4]
Setting the scene numbers for the
different levels.
- Available with "Scene output“.
- level 4 only with setting „4 levels“.
Threshold value 1
(level 1 -> level 2)
Threshold value 2
(level 2 -> level 3)
Threshold value 3
(level 3 -> level 4)
0 … 2000 ppm
[800] [800]
[1200] [1500]
[1700]
0 … 500
[100] [100]
[250] [300]
[400]
Setting range of the threshold values at
which switching is to take place.
(left column: ppm; right column: IAQ))
- Unit depending on setting
"Sensor for air quality traffic light“.
- Threshold value 3 only available
with setting “4 levels".
Sending condition of
output
• not active
• on change
• cyclic
• cyclic and on change
Setting whether and when the output
object is to be sent.
Send cyclically
every…
1 min – 60 min
[60 min]
Setting at which interval the measured
value is sent cyclically.
Only if "cyclic..." is active.
Table 15: Settings – Air quality traffic light
