Je bekijkt pagina 16 van 78
Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
16
16
The setting "Send measured value on change" can be used to set the change on which the sensor
sends its current temperature value. If set to "not active", the sensor does not send a value,
regardless of the size of the change.
The setting "Send measured value cyclically" can be used to set the intervals at which the sensor
sends its current measured value. The cyclical sending function can be activated or deactivated
independently of the setting "Send measured value on change". Measured values are also sent if
the sensor has not detected a change. If both parameters are deactivated, a value is never sent.
Important: After reset/programming, the first measured value is sent after approx. 1 minute.
With the "Messages" function, two message values (upper and lower message value) can be
parameterized. The two functions each have their own communication object.
Principle:
If the upper message value is exceeded, a "1" is sent. If it is undershot again, a "0" is sent.
If the value falls below the lower message value, a "1" is sent. If it is exceeded again, a "0" is sent.
A correction value can be set via the parameter "Calibration value for internal sensor". This is
used to increase/decrease the actual measured value. If, for example, a value of "100" is set, the
measured CO2 value is increased by 100 ppm.
An external sensor can be activated or deactivated via the weighting "Sensor internal/external". If
the weighting is set to 100% internal, no external sensor is activated and no communication object
appears for the external sensor. With any other setting, an external sensor is activated and the
associated object appears. The "mixed" value is sent to the bus via the "Send measured value"
object.
With the "maximum value" setting, the higher of the two measured values (internal/external) is
always output
Important: The external sensor is monitored with a time of 30 minutes. If no new value is received
within this time, only the internal sensor is used!
At the same time, an alarm with a "1" is sent to the "External sensor error" object. If an external
value is received again, the alarm is reset with a "0".
The following table shows the available communication objects:
Number
Name/Object function
Length
Usage
1
CO2 measurement – Send
measured value
2 Byte
Sending the current CO2 measured value
2
CO2 measurement – External
sensor input
2 Byte
Receives the temperature of the external
sensor
3
CO2 measurement – Maximum
value exceeded
1 Bit
Sends a message if the upper message value
is exceeded
4
CO2 measurement – Minimum
value fallen below
1 Bit
Sends a message when the value falls below
the lower message value
5
CO2 measurement – Error
external sensor
1 Bit
Sends an error message if the sensor does
not send a value for a certain time
Table 8: Communication objects – CO2 measurement
