MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
53 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.3 Internal function / manual mode (light channel 1)
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Internal function ■ switch short/long
■ lock / forced guidance
Select the internal function for the
buttons.
Button assignment left/right ■ ON / OFF
■ OFF / ON
Setting the value sent by the
corresponding button.
Lock function buttons
left/right
■ ON / OFF
■ OFF / ON
Select the polarity of the internal
buttons.
Objects for buttons ■ not active
■ active
Displays communication objects.
Only if “switch short/long”
Table 64: Settings – Internal function / manual mode (light channel 1)
Note:
■ Short keypress on “ON”: Starts the follow-up time.
■ Long keypress on “ON”: Switches the light channel to “Manual mode”.
The exact processes for the “Button short/long” are described in the chapter 4.2.1.8 Process diagrams.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Button left short – Switch 1 Bit Switching object for short keypress.
Only if “Object for buttons” → “active”.
132 Button left long – Switch 1 Bit Switching object for long keypress.
Only if “Object for buttons” → “active”.
+5 Button right ...
Table 65: Communication objects – Internal function / manual mode (light channel 1)
