Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.1.2 Basic function: Blinds / Shutter
Two-button function
This function is used to control Shutter Actuators, which can be used to adjust and control shutter and
blinds with slats.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
■ Up/Down
■ Down/Up
Setting the key assignment.
Operating function ■ Long = Up/Down /
Short = Stop / Slats Open/Close
■ Short = Up/Down /
Long = Stop / Slats Open/Close
Setting the operating concept.
Table 44: Settings – Two-button function: Blinds / Shutter
Two communication objects are displayed for the “blinds / shutter” function: The object “Stop / Slats
Open/Close” and the object “Blinds/Shutter Up/Down “.
The moving object is used to move the blinds / shutters “Up” and “Down”.
The stop/step object has two functions: On the one hand, it stops the upward or downward movement if
the end position has not yet been reached, and on the other hand, it is used to adjust the slats.
In the case of the two-button function, the button assignment can be set.
The table below shows the relationships:
Function Up/Down Function Down/Up
Input Button left Button right Button left Button right
Moving object Up Down Down Up
Stop / Step object Stop / Slats open Stop / Slats close Stop / Slats close Stop / Slats open
Table 45: Two-button function – Blinds
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Buttons left/right – Blinds Up/Down 1 Bit Up/down command for the shutter actuator.
132 Buttons left/right –
Slats adjustment / Stop
1 Bit Open/close slats and stop command.
Table 46: Communication objects – Two-button function: Blinds / Shutter
