Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
Follow up time
Thistimedenestheswitch-offdelaythatexpiresafterthelastmotiondetectionuptotheswitch-offof
the output. Thus, with a follow-up time of 3 min, the signalling channel would be switched on for at least 3
min if motion is detected. Each new detection restarts the follow-up time. This time can be set to different
values for Day and Night.
Lock/Release object
This parameter can be used to set which of the two objects will be active. The lock object switches the
channeloffwitha“1”.Thereleaseobjectactivatesthechannelwitha“1”.Iftheparameteriscongured
as a lock object, it is possible to switch the channel ON or OFF with the parameter “Fallback of forced
guidance/lock” whether or not the channel should respond to the “Fallback of forced guidance/lock”
congurationinthe “General settings” menu.
Output objects for “Day” / “Night”
This is where you can set whether to switch via a common object or separate objects for Day and Night.
Separate objects can be used, for example, to execute a different action for Day than for Night.
Output object sends at
Thisparametercanbeusedtoactivateasendinglterfortheoutput.Thislterisusedtospecifywhether
the channel should only send “ON” telegrams or if it should send “ON” and “OFF” telegrams.
Object sends cyclically every ...
This object influences whether and at what intervals the output object sends its value cyclically at an
intervaltobedened.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
75 Alarm - Output – Switch 1 Bit Sending an alarm (common object).
75 Alarm - Output (Day) – Switch 1 Bit Sending an alarm in day mode.
76 Alarm - Output (Night) – Switch 1 Bit Sending an alarm in night mode.
83 Alarm - Input – Lock 1 Bit Locking the Alarm/Message function.
83 Alarm - Input – Release 1 Bit Releasing the Alarm/Message function.
Table 36: Communication objects – Alarm/Message channel
