MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
38 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.2 Alarm/Message channel / Direction of movement
The Detection channel function can be used to monitor a room in case of absence and to call up certain
actions in the KNX system when motion is detected.
Important: The Alarm/Message channel is always brightness independent.
4.2.2.1 Alarm/Message channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Active sensors ■ - -
■ 1 -
■ - 2
■ 1 2
Setting which sensors are active for this
channel.
Information about sensor
assignment
When activated (check box selected with
a mouse click), a graphic appears with
information about the positions of
sensors S1 and S2.
Position of sensors
Trigger sensitivity
“Day”
0 – 6
[3]
Setting the trigger sensitivity.
Level 0 (lowest level) only from DB V4.4
and from Device HW R2.5 possible.
Trigger sensitivity
“Night”
0 – 6
[2]
Presence sensitivity 1 – 8
[6]
Setting the sensitivity when presence is
detected.
Interference/motionlter ■ not active, no ltering
■ active,lterinterference/
short motions
Activationofamotionlterinstandby
(= output is switched off).
Onlyif“Interference/motionlter”→“active,lterinterferences/shortmotions”
Length of monitoring
time slots
1 ... 5 s
[2 s]
Setting the time for how long a time
window is open for detection.
Number of monitoring
time slots
2 ... 5
[3]
Setting how many time windows are open
for detection.
Follow-up time “Day” 1 s – 4 h
[3 min]
Setting the follow-up time in day mode.
