MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
30 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
The following table shows the associated communication objects:
No. Name/Object function Length Usage
3 Light channel 1 - Input –
External button short
1 Bit Object for the input of an external button.
4 Light channel 1 - Input –
External button long
1 Bit Object for the input of an external button.
+15 Light channel 2 ...
63 HVAC - Input –
External button short
1 Bit Object for the input of an external button.
64 HVAC - Input –
External button long
1 Bit Object for the input of an external button.
Table 29: Communication objects – External button short/long
4.2.1.6 Idle time
Light channel
HVAC channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Idle time after external
button short is off
1 s ... 30 s
[5 s]
Setting of the time for which the motion
detector is locked for further detection
after it has been switched off via
“external button short”.
Idle time after switch off 1 s ... 30 s
[1 s]
Setting the time for which the motion
detector is locked for further detection
after the follow-up time has expired.
Table 30: Settings – Idle time
Idle time after external button short is off
This parameter is useful, for example, to leave the room briefly after switching OFF via the “external button
short” without avoiding a renewed switching ON of the light by detection.
