MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
63 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Object number 0 ... 129
[0]
Selection of the internal object that
is active as an input for the logic.
External input C-F ■ not active
■ normal
■ inverted
Activation of an external object as a
logic input and setting whether it
should be used normally or
inverted.
Preset logic input
after reset with ...
■ value “0”
■ value “1”
Setting the value with which an
input is to be pre-assigned after bus
voltage recovery.
Table 75: Settings – Logic
The “Sending conditions” are explained as follows (the texts vary depending on the source object):
■ on input telegram: The output value is sent with every input telegram, regardless of whether the
output value has changed or not.
■ on change of output: The output value is only sent if the output has changed.
■ send only “0”/”1” / Value/Scene for “False”/”True” on change of output: The output value is only
sent if the output changes and the logic has the corresponding value (0/1).
■ send only “0”/”1” / Value/Scene for “False”/”True” on input telegram: Output value is sent with
every input telegram and the logic has the corresponding value (0/1).
Internal inputs can be connected to all existing objects on the device.
Important: Only Bit values can be evaluated correctly.
External inputs can only be linked with 1 Bit objects.
Note:Intheeventofareset(busvoltagefailure/recovery),theexternalinputsareinanundenedstate.In
this case, the inputs can be pre-assigned with values (1/0) in order to maintain the function of the logic.
These values refer up to valid values from the external objects (e.g. status messages).
The following table shows the associated communication objects:
No. Name/Object function Length Usage
110 Logic 1 – Input C 1 Bit External input for the logic function.
+1 Logic 1 – Input D-F
114 Logic 1 – Output 1 Output of the logic function.
DPT depending on the output object parameter.
+5 Next Logic
Table 76: Communication objects – Logic
