MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
5 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
2.2 Functions
2 Light channels
Both or only one of the pyro detectors can be assigned to each light channel. Each channel is configured
separately to obtain two completely independent outputs. For example, the follow-up times for “Day” and
“Night”, the trigger and presence sensitivity, and the lock and unlock behaviour can be set individually.
HVAC channel
Compared to the light channels, the separate HVAC channel (heating, ventilation, air conditioning) has
adjustable observation windows that can be used to monitor the presence in the room. For example, to
control the ventilation of a room.
Alarm/Message channel
The alarm channel has a separate sensitivity setting and is used to detect motion in the event of absence.
Monitoring can be activated by object.
Direction of Movement
The MDT Motion Detector is able to detect the direction of movement. This means, for example, that the
light can be switched off in advance if movement is detected in the direction of the exit.
Integrated white LED light
The white LED light can be switched, for example, via the “Day/Night” object, in “Night” mode when
motionisdetectedinadenedlightchannel,orviaanexternalobject.
Fully automatic, half automatic, manual mode
Conguredas“fullyautomatic”,themotiondetectorswitchesonwhenamotionisdetectedandswitches
off again after the end of the presence and set follow-up time. In the “half automatic” operating mode, the
light must be switched on manually via an object and the motion detector switches off automatically after
the end of the presence and the follow-up time. Regardless of the operating mode, manual operation is
possible at any time via the objects “External button short” and “External button long”.
Sensor buttons (only SCN-BWM55T(06).x2 and SCN-BWM63T.02)
The sensor buttons on the Motion Detector can be used to execute internal functions such as locking or
forced operation, as well as one- and two-button functions such as switching, dimming, blinds or sending
values.
Temperature sensor (only SCN-BWM55T(06).x2 and SCN-BWM63T.02)
When the temperature sensor is activated, the room temperature can be sent to the bus and, for example,
used for heating control. The transmission behaviour of the measured value and a correction value can be
parametrised.
Brightness sensor
Abrightnesssensorisintegratedtoallowdifferentswitch-onlevelstobeconguredfor“Day”and“Night”
mode.
Scenes
A total of 8 scenes are available to the Motion Detector. Each scene can be assigned extensive and
different functions for light channels 1 and 2.
