MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
39 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Follow-up time “Night 1 s – 4 h
[30 s]
Setting the follow-up time in night mode.
Lock or release object ■ lock object
■ release object
Setting whether a locking or release
object is to be used.
Fallback of
forced guidance/lock
(General settings)
■ not active
■ active
Setting whether the channel should react
to “Fallback forced guidance/lock” in the
menu “General settings”.
Only available with “lock object”.
Output objects for
Day/Night
■ one common object
■ separate objects
Setting whether “Day” and “Night”
should be sent via one object or separate
objects.
Output object sends at ■ only ON
■ ON and OFF
Outputlterfortherstoutputobject.
Object sends cyclically
every ...
not active
10 s - 60 min
Activation of cyclic sending and an the
interval for the output object.
Table 35: Settings – Alarm/Message channel
Active sensors
The active sensors can be set for detection channel. This allows the detection range of the channel to be
limited. For example, if only one area in a corridor is to be detected, only one sensor can be activated. The
alignmentofthesensorscanbeidentiedbyactivatingthe“Informationaboutsensorassignment”
parameter.
Trigger sensitivity “Day” / “Night”
These parameters describe the sensitivity in standby mode (the output is switched off, no motion has been
detected).
Presence sensitivity
This parameter is used to set the sensitivity in presence mode (the output is switched on, motion has
already been detected).
Interference / Motion Filter
Toavoidfalsedetections,ainterferenceandmotionltercanbeactivatedthatltersoutveryshort
motions,e.g.causedbydrafts.Ifthislterisactivated,theparameters“Length of monitoring time slot”
and “Number of monitoring time slots” can be set.
This has the effect that a longer detection is required for switching on. To switch on the channel, at least
one detection must have occurred in each of the set observation time windows. For example, if there are
threeobservationtimeslots,eachwithalengthof2seconds,atleastonedetectionmustoccurintherst
2 seconds, at least one detection in the second 2 seconds and at least one detection in the third 2
seconds.
Ifthemotionlterisnotactivated,adetectionwilloccurifthereisonlyonemotionwiththesensitivityset
accordingly.
