Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
Standard settings – Logic
No. Name Object function Length
C R W T U
110 Logic 1 Input C 1 Bit
■ ■ ■ ■
111 Logic 1 Input D 1 Bit
■ ■ ■ ■
112 Logic 1 Input E 1 Bit
■ ■ ■ ■
113 Logic 1 Input F 1 Bit
■ ■ ■ ■
114 Logic 1 Output 1 1 Bit
2 Bit
1 Byte
■ ■ ■
+5 next Logic
Table 9: Communication objects – Standard settings: Logic
Standard settings – General settings
No. Name Object function Length
C R W T U
90 Day/Night Day = 0 / Night = 1 1 Bit
■ ■ ■ ■
90 Day/Night Day = 1 / Night = 0 1 Bit
■ ■ ■ ■
95 In operation Output 1 Bit
■ ■ ■
Table 10: Communication objects – Standard settings: General settings
The table above shows the preset default settings. The priority of the individual communications objects
and the flags can be adjusted by the user as required. The flags assign the communication objects their
respective tasks in programming, where C stands for communication, R for read, W for write, T for transmit
and U for update.
