Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
64
64
The temperature can be shifted in 4 different ways:
1 Bit temperature shift
With the 1-bit temperature shift, the push-button sends a "1" for an upward shift of the setpoint and
a "0" for a downward shift of the setpoint.
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
0
F1/2: – Setpoint shift
1 Bit
Sends the Setpoint shift
1
F1/2: –
Status actual temperature
2 Byte
Receiving an external temperature for the display
of the current temperature - is only displayed if the
parameter "Use internal temperature value" is set
to "not active"
2
F1/2: –
Status current setpoint
2 Byte
Receiving the current setpoint temperature of the
temperature controller – to display the status
Table 46: Communication objects – Temperature shift via 1 Bit
1 Byte temperature shift
With the 1-byte temperature shifting, the Push-button sends a 1-byte value which is multiplied by
the step width set in the controller. In order for the display and the current setpoint value to be
synchronous, the step width and the limits of the setpoint shift have to be specified in the Push-
button.
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
0
F1/2: – Setpoint shift
1 Byte
Sends the Setpoint shift
1
F1/2: –
Status actual temperature
2 Byte
Receiving an external temperature for the display
of the current temperature - is only displayed if the
parameter "Use internal temperature value" is set
to "not active"
2
F1/2: –
Status current setpoint
2 Byte
Receiving the current setpoint temperature of the
temperature controller – to display the status
3
F1/2: –
Status setpoint shift
1 Byte
Reception of the current setpoint shift. Must be
connected to all 1-byte objects that send the
setpoint shift to the controller to be controlled in
order to correctly evaluate the current status of the
setpoint shift.
Table 47: Communication objects – Temperature shift via 1 Byte
