Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
61
61
Special presentation
For certain data point types, a special presentation (see table above) is possible. In this presentation,
the status is shown on a larger scale on the display.
The following presentations are possible:
ETS-Text
Dynamic range
[Default value]
Comment
Special presentation
▪ bar symbol
▪ bar symbol with fan
▪ value as text (0-100%)
▪ value as text (0-255)
Only for DPT 5.001 and DPT 5.005.
If "bar symbol" and "bar symbol with
fan" are selected, the corresponding
symbol is presented, and the bar is
filled depending on the current status.
If "value as text" is selected, the text
is shown large on the display.
Special presentation
▪ value as symbol + “°C”
▪ value as symbol without unit
▪ value as symbol + “K”
Only for DPT 9.001.
With the settings "value as symbol",
the text is shown large on the display.
Table 44: Special presentation – Send values
