Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
50
50
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
0
F1:
F1/2:– Switch control, Percent value …
Switch function of the button(s).
DPT depending on the parameter setting.
1
F1:
F1/2: –
Status for display
Receiving the status for the display.
DPT depending on parameter setting.
Status for RGB value not available.
2
F1 (2. object)
F1/2 (2. object) –
Switch control, Percent value …
Switch function of the button/s on the
second object.
DPT depending on the parameter setting.
2
F1 Group long
F1/2 Group lang – Switch control,
Percent value …
Switch function with long keystroke.
DPT depending on the parameter setting.
4
F1 Group extra long
F1/2 Group extra long – Switch
control, Percent value …
Switch function with extra long keystroke.
DPT depending on the parameter setting.
Table 32: Communication objects – Send values - Subfunction: Send values
Note: The object numbers for the slap-button are 84 - 88. There is no "Status for display" object.
4.4.5.2 Subfunction: Toggle Values/Scenes (up to 4 Values)
Single-Button function
Two-Button function
Slap-Button
This function can be used to switch between up to 4 different values of a datapoint type.
The following picture shows the available settings, here with the two-button function:
Figure 26: Settings – Send Values - Subfunction: Toggle values/scenes (up to 4 values)
