Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
30
30
Colour of message text
Any colour
[red]
Setting of the colour for the
message text.
Indicate a message via
LEDs
▪ not active
▪ active
Setting if the LEDs should flash at
an active message.
Colour of LEDs
Any colour
[red]
Select the colour in which the
LEDs display the message.
Only visible if "Indicate a
message via LEDs" is activated.
Table 15: Settings – Messages
The message behaviour depends on the parameter "Standby display during “Day / Night". The
different behaviours are shown below:
Standby display
Incoming message during Standby
No Standby
▪ No message is displayed but saved
Standby in upper
keypad
▪ Message is displayed on upper button pair and the upper LEDs
change between parameterized colour and black at 600ms pulse
▪ At the same time, the parameterized colour is set to double
brightness in order to increase the signal effect
▪ The message is only acknowledged by pressing to one of the upper
buttons.
▪ A keystroke on the middle and lower buttons performs the displayed
switching functions
Standby over full
screen
▪ Message is displayed in the middle of the screen and all LEDs change
between parameterized colour and black
▪ At the same time, the parameterized colour is set to double
brightness in order to increase the signal effect.
▪ The message is acknowledged by pressing to any key
Display off
▪ No message is displayed during standby but saved.
▪ The message with the highest priority is indicated by the keystroke
after Standby
▪ The displayed messages are acknowledged by means of further
keystrokes
▪ Message is displayed in the middle of the screen and all LEDs change
between parameterized colour and black
▪ At the same time, the parameterized colour is set to double
brightness in order to increase the signal effect.
Display off and
orientation-LED on
▪ Message is displayed in the middle of the screen and all LEDs change
between parameterized colour and black.
▪ At the same time, the parameterized colour is set to double
brightness in order to increase the signal effect.
▪ After the "time until Standby", the LEDs will stop flashing and the
message disappears.
▪ If any button is pressed after the LEDs have stopped flashing, the
message with the highest priority is displayed again. Further
keystrokes acknowledge the messages
Table 16: Behaviour of the device to an incoming message during Standby
