Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
61
61
4.6.9 Scene
Single-Button function
The scene function allows you to call up and save scenes that cover different trades. If the memory
function is activated, it can be executed by pressing and holding down a key.
The following figure shows the available settings:
Figure 31: Settings – Scene
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Save scene
▪ no save
▪ save
Release of saving the scenes;
the saving is carried out by a
long keystroke
Time for long keypress
Basic setting
0,1 s – 30,0 s
[1,0 s]
Only visible if "Save scene" is
active.
Setting the time for the long
keypress to save a scene
Scene number
1 – 64
[1]
Setting the respective scene
number
Table 50: Settings – Scene
The following table shows the available communication objects:
Number
Name
Length
Usage
2
Push button 1 – Scene
1 Byte
Call up/saving of scenes
Table 51: Communication object – Scene
Presentation:
Single-Button function
The scene function is represented by a fixed symbol. Since the scene function does not get a status,
the function is represented by a fixed symbol:
Figure 32: Presentation – Scene
