Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
59
59
Action with long
keypress
▪ Comfort
▪ Standby
▪ Night
▪ Frost
Setting which operating mode
should be called with a long
keystroke
Only available with single-button
function!
Switching type
▪ Limit stop
▪ Overrun
Only available with two-button
function!
Setting what should happen when
the last switching value is reached
Switchover considers
status object
• Yes
• No
Setting whether the changeover
should send the next switching value
according to the current status
Status display
▪ HVAC-Mode
▪ HVAC-Status
Setting how to display the status
Table 48: Settings – Mode selection
Function principle:
The function "mode selection" can send up to 4 different operating modes by shortly pressing a
button. The operating modes are switched one after the other. Depending on the set parameters, for
example, at a keystroke the second operating mode is sent if the 1st operating mode has been sent
before or the third operating mode will be sent if the second operating mode has been sent before…
Parameter “Push button long”:
In addition to switchover by a short keystroke, a fixed operating mode can be sent at a long
keystroke.
Here one of the 4 operating modes can be sent. This means that a fixed operating mode
(independent of the last switching value) would always be sent with a long keystroke.
Parameter “Switching type”:
Limit stop: With the switching type "Limit stop" the 4th operating mode is sent again after sending
the 4th operating mode.
Overrun: In the switching type "Overrun", the 1st operating mode is sent again after the 4th
operating mode.
For the single-button function, this parameter is set permanently to "Overrun".
Switchover considers status object:
If the status value is not taken into account when switching over, the device remembers the last
value sent and sends the next or previous value the next time it is pressed, regardless of whether
another value has been sent to the object in the meantime.
If the status value is taken into account in the changeover, the device sends the next higher or next
lower changeover value - with reference to the last received status value - the next time it is pressed.
If, for example, the value "1K" was sent when the last key was pressed and then the value "2K" was
sent from another location, the value "2.5K" is sent the next time the "+" key is pressed.
