Je bekijkt pagina 47 van 89
Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
47
47
Value tip
once/twice/triple
any value according to set datapoint type
Setting the respective value
for the switching value
3./4. Function
(long keypress)
▪ not active
▪ active
Setting an additional
function with a long keypress
Datapoint type for
long keypress
▪ 1Bit DPT 1.001 Switch
▪ 2Bit DPT 2.001 Switch Control
▪ 1Byte DPT 5.001 Percent (0…100%)
▪ 1Byte DPT 5.005
Decimal factor (0…255)
▪ 1Byte DPT 17.001 Scene number
▪ 2Byte DPT 7.600
Color Temperature (Kelvin)
▪ 2Byte DPT 9.001 Temperature (°C)
▪ 2Byte DPT 9.004 Brightness (Lux)
▪ 3Byte DPT 232.600
RGB Value 3x(0…255)
Setting the action for a long
keystroke
Value for long
keypress
any value according to set datapoint type
Setting the respective value
for the toggle value
Time for long keypress
Basic setting
0,1 s – 30,0 s
Setting from when a long
keystroke is detected
Max. time between two
operations
0,1 s – 30 s
[0,5 s]
Setting an individual time
between two button
operations
Table 35: Settings – Send values - Subfunction: Multi-tip function
There is a special feature in the way the status value is displayed:
If a "common object/DTP" is selected for the multi-tip function, i.e. all tip values are from the same
DTP, then the displayed status is also from this DPT.
If "different objects/DTP" is selected for the multi-tip function, an additional parameter "Datapoint
type object for display" appears. Here - independent of the tip values - a separate DTP can be
selected for the status to be displayed. For some settings, e.g. temperature, the display of the value
can also be specified. For example, whether in "°C" or "K".
The following table shows the available communication objects:
Number
Name
Length
Usage
0
Push button 1 –
Forcible control, Percent value...
Sending the tip value if common object/DPT.
DPT depending on the parameter setting
0
Push button 1, 1x tip:
Sending the tip value when different
objects/DPT. DPT depending on the
parameter setting and number of operations.
1
Push button 1, 2x tip:
2
Push button 1, 3x tip:
3
Push button 1 long: –
Forcible control, Percent value...
Transmission of the value for long keystroke;
DPT depending on the parameter setting
4
Push button 1 –
Status for display
Receiving the status.
DPT depending on the parameter setting
Table 36: Communication objects – Send values - Subfunction: Multi-tip function
