Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
28
28
Standby display
Incoming message during operation
no Standby
▪ No message is displayed but saved
Table 16: Behavior of the device to an incoming message during operation
Standby display
Incoming message while Standby + Display brightness „Off“ via
brightness sensor
no Standby
▪ No message is displayed but saved
Standby in upper
keypad
▪ Brings display back to life (dark background lighting)
▪ After the "timeout for standby" has expired, the backlight is
switched off again.
▪ Otherwise as in Standby
Standby on full screen
▪ Brings display back to life (dark background lighting)
▪ After the "timeout for standby" has expired, the backlight is
switched off again.
▪ Otherwise as in Standby
Display off
▪ Like in Standby
Display off and
orientation-LED on
▪ Brings display back to life (dark background lighting)
▪ After the "timeout for standby" has expired, the backlight is
switched off again.
▪ Otherwise as in Standby
Table 17: Behavior when incoming message at standby and the operation switched off
The following table shows the available communication objects for alarms/messages:
Number
Name
Length
Usage
61
Message 1 (highest
priority)
1 Bit
Triggering a message
62
Message 2
1 Bit
Triggering a message
63
Message 3
1 Bit
Triggering a message
64
Message 4
1 Bit
Triggering a message
65
Message text (lowest
priority)
14 Byte
Triggering a message; Send any message text
Table 18: Communication objects – Messages
