Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
19
19
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Background colour
▪ Day = black; Night = black
▪ Day = white; Night = black
▪ Day = black; Night = white
▪ Day = white; Night = white
Sets the background colour of the
display
Font size for Function
name / Value / Key
labelling
▪ Small
▪ Big
Setting the font size in which the
listed positions are shown on the
display. Status elements in
standby are always shown small!
Behaviour at presence
▪ Display (LEDs) is switched on
▪ Display (LEDs) is switched on
and Standby is exited
Setting the action for a "1" or "0"
telegram on the presence object
Brightness
Display brightness
Day/Night
dynamic
0 – 100 %
Setting whether the display
brightness should be dynamic or
whether the display should have
fixed brightness values for
Day/Night.
Global brightness for
LEDs Day/Night
▪ disabled
▪ as display
▪ Brightness level 1 – 5
Brightness setting for all status
LEDs for Day and Night
Datapoint type for
dynamic brightness
▪ 2 Byte DPT 9.004 Ambient
Brightness (Lux)
▪ 1 Byte DPT 5.001 Percent value
(0 … 100%)
Setting of the DPT to control the
dynamic brightness.
Only visible if at least one
"Display brightness Day/night"
parameter is "dynamic".
Control via brightness values: if "2 byte DPT 9.004 ambient brightness (lux)" is active
Minimum Brightness
Day
0 – 100%
[10%]
Setting a minimum brightness
level in daytime operation
Minimum Brightness
Night
0 – 100%
[3%]
Setting a minimum brightness
level in nighttime operation
Ambient brightness
for 100% brightness
0 … 1000 Lux
[500 Lux]
Defines the brightness level at
which the display reaches its full
brightness
Night shutdown
Display/LEDs in
Standby
0 … 100 Lux
[25 Lux]
Setting a brightness threshold for
the display and LEDs to switch off
completely when the brightness
falls below the threshold or to
switch on again when it rises
above it. Applies only at Night!
Control via percentage values: if "1 byte DPT 5.001 percentage value (0 ... 100%)" is active
Minimum Brightness
Day
0 – 100%
[10%]
Setting a minimum brightness
level in daytime operation
Minimum Brightness
Night
0 – 100%
[3%]
Setting a minimum brightness
level in night time operation
Table 9: Display settings – Presentation and Brightness
