Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
72
72
4.7 Status LED
4.7.1 LED basic settings
The LED basic settings affect all active status LEDs. The following figure shows the available settings:
Table 66: Basic settings – LED
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
LED-color at button activation,
only by setting “Object and
button activation”
off, red, green, yellow, blue,
pink, cyan, white
Parameter is only used at double
assignment: "Keystroke + internal /
external object"
LEDs behavior in Standby
▪ Off
▪ Orientation LED
▪ Status-LED
Setting how the LEDs are used
during Standby mode
Color of orientation-LEDs in
Standby
off, red, green, yellow, blue,
pink, cyan, white
Colour adjustment when used as
orientation LEDs
Lock object for LEDs
▪ not active
▪ active
Activates a lock object which can
disable (= switch off) all LEDs
Behaviour of LEDs at bus
power up
▪ no request
▪ request
Setting whether to actively request
the objects after a reset. Only
active when "LED reacts to
external object"
Synchronisation object for
flashing LEDs
▪ not active
▪ active as Master
▪ active as Slave
Setting whether the synchronous
LED object is active and whether it
is used as Master/Slave. This allows
the flashing of several buttons to
be synchronised.
Table 67: Basic settings – LED
