Two communication objects are displayed for the "blind" function: the object "Stop/slat open/close"
and the object "blinds up/down “.The moving object is used to move the blinds/shutters up and
down. The stop/step object is used to adjust the slats. In addition, this function stops the up/down
movement as far as the end position has not yet been reached.
In the case of the two-button function, the key assignment can be set; the table below shows the
relationships:
Table 54: Two-button function – Blind function
The single-button function is used to toggle between the up and down movement after each
keystroke.
As blind actuators always use a 1 signal for down movement and a 0 signal for up movement, the
push-button also outputs this signal.
It is also possible to swap the action for the long and short push-button action. Thus, it is possible to
select whether a long or a short keystroke is to be used. The stop/step object then adopts the other
operating concept.
Only one object is available as "Status for display". It refers to the height position. A position for the
slat cannot be visualised.
Group control extra long
If the key is pressed extra long, the single blind starts moving after 0.5 s.
After another 1.5 s, the group starts with the same movement.
This activates the group function:
If Stop is then pressed briefly, all blinds stop. If the slat is adjusted with "short", the group also
adjusts the slat.
After approx. 90 s the group function is deactivated again internally and a Stop only affects the
individual channel.
MDT Single Object Control:
Two-Button function
MDT Single Object Control enables a new operating concept for controlling roller shutters. For use,
the following parameter has to be set to active in the MDT shutter actuator to be controlled:
Now it is possible to start the up/down movement with a short keystroke and also to stop an active
up/down movement with a short keystroke.
With the setting "Short = Up/Down/Stop / Long = Central object (MDT Single Object Control)" an
additional object is displayed, which can start the up/down movement with a long keystroke and can
also stop an active up/down movement with a long keystroke. This function can be used, for example,
to move a single shutter in a room with a short keystroke and to move the entire room with a long
keystroke
Function Up/Down
Function Down/Up
Input
Push button left
Push button right
Push button left
Push button right
Moving object
Up
Down
Down
Up
Stop/Step object
Stop/slats open
Stop/slats close
Stop/slats close
Stop/slats open
