Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
46
46
4.6.5.5 Subfunction: Multi-Tip Function (Send values after number of operations)
Single-Button function
Depending on how often the key is pressed, the multi-tip function can send a fixed value according to
the set data point type.
Note: A fast response time is recommended for the tip function.
The following figure shows all available settings:
Figure 23: Settings – Send values - Subfunction: Multi-tip function
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Output objects
▪ Common object / DPT
▪ Different objects / DPT
Setting the available data points
(single or separate objects)
Numbers of tip-
operations
▪ 2x
▪ 3x
Settings of the possible tip-
functions
Datapoint type
▪ 1Bit DPT 1.001 Switch
▪ 2Bit DPT 2.001 Switch Control
▪ 1Byte DPT 5.001 Percent (0…100%)
▪ 1Byte DPT 5.005
Decimal factor (0…255)
▪ 1Byte DPT 17.001 Scene number
▪ 2Byte DPT 7.600
Color Temperature (Kelvin)
▪ 2Byte DPT 9.001 Temperature (°C)
▪ 2Byte DPT 9.004 Brightness (Lux)
▪ 3Byte DPT 232.600
RGB Value 3x(0…255)
Set the data point type for the
value to be sent.
Available for selection:
only one datapoint type if
“Common object/DPT”
or:
Datapoint type 1x/2x/3x
pressed if
“Different objects/DPT”
