Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
29
29
4.5 Button Setting
In the menu "Button settings", you can activate/deactivate the individual buttons independently of
each other. The following settings are available:
Figure 10: Basic Settings – Push buttons
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
Key alignment for two-
button function
▪ horizontal (left/right)
▪ vertical (top/bottom)
Setting the alignment for a key
pair
Buttons 1/2 – 3/4
▪ not active
▪ Two button function
▪ Single button function
Operating mode of the
respective keys
Position of the label/value
▪ Above the symbol
▪ Below the symbol
Determines whether the label
appears below or above the
symbol in the display
Reaction time on keystroke
▪ fast
▪ medium
▪ slow
Setting the reaction time or
debounce time for the keys
Time for long keystroke
(Basic setting)
0,1 s – 30 s
[0,4 s]
Setting from when a long key
press is detected
Table 19: Basic Settings – Push buttons
With the key alignment, you can freely set for the two-button function whether the rocker should
work right/left or top/bottom.
For the buttons 1/2 or 3/4, you can choose between a single-button or two-button function. A
mixture, e.g. two single keys and a rocker, is also possible. When deactivated, no parameters are
displayed..
The parameter "Position of the label/value" defines whether a label or value is to be displayed as
text/character above or below the symbol. This is a general specification and applies in the following
to all buttons for which either a function name or a value is stored under the parameter "Display".
The reaction time is the debouncing of the keys. It can be selected as slow, medium or fast and
defines how long a key has to be pressed to generate a function call.
Note: A fast response time is recommended for the tip function.
With the help of the parameter "time for long keystroke", a fixed time value can be assigned to the
key, from when on the key recognises a keystroke as long. This parameter is important for objects
which have both short and long keystroke functions.
